Bag Filter with Cyclone Dust Collection System Description
The Bag Filter with Cyclone Dust Collection System combines the advantages of both baghouse filters and cyclone dust collectors to efficiently process and filter particulate matter from industrial gases. This type of equipment is frequently used in industrial applications with high dust concentrations, coarse particles, and situations requiring secondary treatment, such as in cement plants, mining, steel mills, chemical plants, and other facilities where efficient particle removal is essential.
1. Working Principle
The Bag Filter with Cyclone Dust Collection System separates dust in two main stages:
- Stage 1: Cyclone Separation Dust-laden air first enters the cyclone separator. Through the centrifugal force generated by the rotating airflow, larger particles are separated and settle into the dust collection bin. This stage mainly removes coarse dust particles, reducing the dust load entering the bag filter system, thus extending the lifespan of the filter bags.
- Stage 2: Baghouse Filtration After cyclone separation, the air enters the bag filter, where fine particles are removed. As the air passes through the filter bags, fine dust is trapped on the surface of the bags, and the cleaned air is discharged through the bags. As dust accumulates, a pulse-jet cleaning system periodically blows compressed air to remove dust from the surface of the filter bags, maintaining filtration efficiency.
2. Key Features
- Efficient Dual Filtration: The combination of cyclone and baghouse filtration allows the system to effectively remove particles of various sizes, making it particularly suitable for treating exhaust gases containing both coarse and fine dust.
- Extended Bag Life: The cyclone separator reduces the dust load entering the filter bags, thus prolonging the lifespan of the bags and lowering the operating and maintenance costs of the system.
- High Filtration Efficiency: The bag filter system can achieve very high filtration efficiency, typically removing over 99% of dust particles, meeting stringent environmental emission standards.
- Automatic Cleaning System: The pulse-jet cleaning system ensures that the filter bags do not fail due to dust accumulation, maintaining stable operation of the equipment.
3. Advantages
- High Efficiency through Dual Filtration: The combination of cyclone separation and baghouse filtration effectively handles dust particles of various sizes and ensures high filtration efficiency.
- Reduced Maintenance Requirements: The cyclone separator lessens the load on the baghouse filter system, reducing the frequency of filter bag replacements and cleanings, thereby lowering maintenance costs.
- Strong Adaptability: The system can be adapted to various industrial applications, especially in situations with high dust concentrations and varied particle sizes.
4. Applications
The Bag Filter with Cyclone Dust Collection System is suitable for the following industrial sectors:
- Cement Industry: For dust removal during cement production, especially in processes such as grinding, conveying, and mixing.
- Steel Industry: For handling smoke and dust generated during steel smelting and processing.
- Mining and Mineral Processing: For effectively removing particulate dust generated during ore crushing and screening processes.
- Chemical Industry: For handling fine dust released during chemical production, ensuring a clean production environment.
型號Model 馬力(HP) 長 (mm) 寬 (mm) 高 (mm) 處理風量 (CMM) CHBI-1 1 880 600 2100 15 CHBI-2 2 980 600 2100 20 CHBI-3 3 980 600 2100 25 CHBI-5 5 1500 800 2500 40 CHBI-7.5 7.5 1725 1150 4000 65 CHBI-10 10 2225 1150 4000 85 -
